PRODUCT DESCRIPTION

• Impact ELP extra low profile R65 8 LED beacon
• Built-in flasher with up to 24 selectable patterns
• Night dim and cruise modes
• Synchronisation capability for multiple units
• Permanent mount
• 10-40VDC for 12 or 24V use
• Single colours - R65 Class 1 amber, Class 2 blue, Class 2 red
• Optional additional rotating flash patterns - R65 Class 1 blue
• Clear or coloured lens
• Split colours also available - contact sales for more info

When operating in cruise mode, activating flash mode overrides cruise mode and restores full power flashing.

Manufactured in the UK by Haztec

Datasheets - Haztec 3-3751 Impact ELP 8 LED Beacon Instructions - 3-3751 Extra Low Profile 8 LED Beacon (M019.1.5) Instructions - 3-3751-F Extra Low Profile 8 LED Beacon with Optional Rotating Patterns (M215.1.2)

SPECIFICATIONS

• Profile: Extra Low Profile
• No of LEDs: 8
• Flash Patterns: Up to 24 Flash Patterns
• Dimensions: 58mm High x Diameter 106mm (Lens) / 134mm (Base)
• R65 Certifications: R65 Class 1 Amber, Class 2 Blue, Class 2 Red (Class 1 Blue Additional Rotating Flash Patterns)
• Supply Voltage: 10-40V
• Material: Strong UV Stabilised Polycarbonate Lens, with a Rugged Powder Coated Cast Metal Base
• Type of Mount: Permanent
• Warranty: 5 Years
